THE OFF GRID MODULE
TSM-PC26
TSM-PC26
TSM-PC26
TSM-80 PC 26
TSM-85 PC 26
Peak Power Watts-PMAX (Wp)
80
85
Maximum power Voltage-VMp (V) 1 17.5
17.9
Maximum power current-IMpp (a) 4.57
4.75
Open circuit Voltage-Voc (V)
22.0
22.2
Short circuit current-Isc (a)
4.89
4.99
Cells orientation
36 cells (4 × 9)
Module dimension
941 × 670 × 40mm
941 × 670 × 40mm
* IP65 Rated
Anodized aluminium alloy
Maximum Ratings
Operational Temperature -40~+85°C
Maximum System Voltage 1000VDC
Max Series Fuse Rating 15A
Warrenty
5 years workmanship warranty
25 years performance warranty
THE OFF GRID MODULE
TSM-PC 24 /
TSM-PC26
TSM-PC20
TSM-135 PC 20
TSM-140 PC 20
Peak Power Watts-PMAX (Wp)
135
140
Maximum power Voltage-VMp (V) 17.6
17.9
Maximum power current-IMpp (a) 7.68
7.83
Open circuit Voltage-Voc (V)
22.0
22.3
Short circuit current-Isc (a)
8.15
8.30
Cells orientation
36 cells (4 × 9)
Module dimension
1500 × 670 × 40mm
1022 × 670 × 40mm
* IP65 Rated
Anodized aluminium alloy
Leading Quality, Superior Yield,
Smarter Solutions
Increase your bottom line
- Cut your electricity bill and protect your business from
rising energy expenses
- Generate revenue from renewable energy subsidies
Increase your property value
Reduce your carbon footprint
- Fulfill your sustainability objectives
