In many situations, particularly when people are concerned about security, there is a tendency to over-light a park, plaza, street, or other public space. But in fact, too much lighting can be just as bad as too little lighting.
The key to developing a good plan is to relate lighting to the evening functions of a particular space, because in the larger view, street lighting is more than just a technical requirement, a security need, or a design element. It can be thought of and utilised in terms of how the type, placement, and wattage affect how a street is perceived and used.
Although its primary purpose is night-time visibility for security and safety, successful street lighting takes into account the human users of the street, not simply the requirements set by local public works agencies. For instance, one way to emphasize pedestrian activity over automobile traffic is to replace standard overhead street lights with smaller-scale, more frequently spaced fixtures geared to pedestrians.
Why is lighting important?
- Increases safety in areas that people use, such as doorways and bus stops.
- Aids in geographic orientation, as people can use well-lit focal points (fountains, buildings, bridges, towers, sculpture, et al.) as landmarks to help them find their way.
- Highlights the identity and history of an area, for well-lit historic details draw attention to the uniqueness of an area.
- Creates a sense of drama.
What are the ways to use lighting?
- Landscaping: Trees lit with small white ‘bee’ lights have become a popular sight in many cities even outside the holiday season, perhaps because they impart a magical feeling and bring positive attention to streets and public spaces.
- Transit stops: People feel more secure when bus, train, or trolley stops are well-lit. Lighting also draws attention to and encourages use of such amenities.
- Entrances: Careful evening lighting around building entrances – especially in residential building doorways – contributes to the safety of an area even more than indiscriminate use of bright lighting that is not focused on areas of use.
- Edges: The edges of a park or plaza – particularly any interesting gateposts, fences, and specimen trees visible from the adjacent street – should be lit to help define and identify the interior space. Buildings located on the edges of a park can also have seasonal lights, bringing attention to the larger area beyond the park.
- Retail displays: Lighting retail displays, even when stores are closed, not only provides ambient light for the street, but also encourages window-shopping. This tactic can help to increase the number of people on a street, which is a major contributor to security.
- Architectural details: Lighting entrances, archways, cornices, columns, and so forth can call attention to the uniqueness of a building, place, or an area and bring a sense of drama to the experience of walking at night.
- Signage: Well-lit maps, along with directional and informational signage, are essential to providing orientation at night.
- Focal points: Lighted sculpture, fountains, bridges, towers, and other major elements in an area, especially those visible to passing pedestrians and vehicles, provide another form of wayfinding.
- As a traffic-calming device: The difference between a pedestrian-lit street and a highly illuminated highway automatically signals drivers that they have entered a new and different zone, and compels them to slow their driving speed.
How much lighting is enough?
Different sources of illumination vary significantly with respect to the quality of light they provide. This, in turn, has a dramatic effect upon the appearance and safety of the street at night. High-pressure sodium, the light source typically used in city street-light fixtures, casts a yellowish-orange glow that results in poor colour rendition; it compromises visual clarity and detracts enormously from the overall quality of the night-time urban environment. By contrast, metal halide as a light source produces a soft, white glow that renders colour accurately; it offers better visual clarity, improves reaction time for vehicles, and requires less wattage for the same perceived visibility. LED lighting, however, is becoming the standard today.
Quality of light is also influenced by quantity of light – or more specifically, by the relationship between the brightness of a light and one's distance from it. Light becomes more diffuse farther away from the source, so for a given brightness, there is a range of heights within which the source should be located to create the desired quality of light.
Height of the luminaire: Although luminaire mounting heights have typically increased over the past few decades as lamp technology has allowed for higher and brighter road lights, the result is often lighting designed for the car or the parking lot, not for the person walking on the side of the street. Reducing the luminaires' height, and adjusting it to the scale of the person on the sidewalk, calls for more fixtures, which in turn means that the luminaires, the poles, and their placement can have an impact on the streetscape.
Type and wattage: However, as a luminaire's height is lowered, the lamp's brightness must be adjusted so that is does not create excessive glare for pedestrians. At the same time, the wattage must also be capable of adequately lighting the road. For instance, 2,5-3 m luminaires might be augmented with overhead lights because, depending on the street width, the wattage needed to light the street would create a blinding glare for the pedestrian.
Sidewalk placement: In addition to the technical criterion of the lights themselves, the distribution of lightposts along the street can have a dramatic effect on the nature of the street and its secondary uses.
- Staggered arrangement: Staggering lightposts across the street from each other allows for an arrangement that is less formal, and can potentially use fewer lights, since there will be some overlap illumination.
- Opposite arrangement: Light fixtures that are aligned directly across the street from each other set up a more formal condition. Opposite arrangement allows for spanning the street with banners or holiday lights.
- Sensitivity to existing conditions: Although a standard distance between street lights might be specified, make allowances to respond to existing or recommended circumstances, such as a street café, compatibility or conflict with existing traffic signals, benches, bus stops, and telephones.
- More closely spaced lightposts create a stronger edge along the sidewalk, reinforcing the sidewalk itself as an exterior habitable space.
- Using more numerous and closely spaced light fixtures is one way of lowering the wattage, and therefore potential glare, of each fixture.
Street scale is an important factor in determining the appropriate configuration of street light fixtures. Broad avenues require fixtures of a different scale from narrow side streets, because the arc of light created by a source varies with its height from the ground. Very wide streets may also require that the light source be extended further over the roadbed. Getting light back onto the sidewalk, on the other hand, requires a pedestrian fixture at a lower height.
Photometric analysis is an important means of determining the appropriate spacing of light fixtures to ensure that light is spread evenly where it is needed.
Other factors
Street character
Special conditions relating to street character are also important considerations in determining an appropriate fixture. Qualities such as the architectural or historical character of the building or park edge, the existence and density of a tree canopy, and the degree of ambient light are all factors. Each of these characteristics can strongly impact the effectiveness and appropriateness of various light fixtures and must be included in the analysis of lighting concepts.
For instance, if the main use of the street is to channel a rapid flow of traffic (e.g., a highway or major arterial), the recommended light level would differ from that of a low-traffic residential street - which should in turn differ from a pedestrian-oriented downtown street. Street lighting that is implemented as part of an overall streetscape design in conjunction with other elements, such as benches, bus stops, and waste receptacles, will reflect the pedestrian-oriented quality of the street, and can potentially enable the off-street area (sidewalks, plazas, pocket parks) to be more conducive to pedestrian and merchant activities.
Compatibility and coordination
The choice of light fixtures must meet the community's preferences, based on the character of the street and surrounding neighbourhood. Factors to consider include number of luminaires per post (single, double, or lighting standards with three or more); materials, colours, and finishes; and historical or contemporary style. Finally, in order to design the street as a public space, light fixtures should be conceived of as part of a coordinated line of amenities - not pieced together from a variety of incongruous components. They should appear compatible with litter receptacles and other street furniture.
In addition, different light fixtures that serve different purposes should relate to one another as part of a family of fixtures. This means that, in a given family, each of the fixture components (base, pole, luminaire) should have stylistic compatibility, while varying in form according to functional requirements. In addition, items that are attached to the fixtures (signs, signals, signal box, etc.) should coordinate in appearance, and the systems for attaching them should be integrated as parts of a whole, rather than being sloppily fastened on as an afterthought.
Existing conditions
Ultimately, every situation has a different set of variables, and the light levels must be considered for each specific location. In addition to dealing with the characteristics described above, lighting levels and an overall lighting plan must be derived from a number of existing conditions (listed below), with other desired factors also taken into account.
- Street width.
- Sidewalk width.
- Path width (in parks or plazas).
- Typical height of buildings.
- Number, placement, and types of trees.
- Types of paved surfaces.
- Roadway geometries.
- Length of the block.
Secondary functions for lightpoles
- Individual pole decorations or banners: These can utilize single or double attachments to the post. The luminaire height may affect the length of a side banner. Attachments should be carefully detailed to complement the lighting style and materials.
- Street-spanning banners or decorations for holidays or special events: Span-wires to support accessory street ornamentations must be located at least 4.5 m above street level. The height must be sufficient to clear automobiles and trucks, while also relating to the surrounding height of buildings and/or the character of open spaces. Note that street-spanning banners are not allowed by all city codes, and careful attention must be paid to wind loads and attachments.
- Planters: Best is either a non-irrigated, hanging planter or an irrigated model with an enclosed pipe within the light pole
- Additional electrical capacity may also be needed to assist in street, tree, and/or event lighting.
