Philippi-Hagenbuch Sideboards are installed quickly and precisely fit to vertically extend the sides of off-highway haul truck bodies. The company works with each operation to custom engineer Sideboards to achieve the optimal height based on the truck’s rated weight, the hauled material, and the loading equipment. Sideboards increase the haul truck’s capacity while reducing or even preventing spillage, keeping haul roads clean — reducing downtime to clear the road — and protecting haul truck tyres.
“We have decades of experience in providing custom and incredibly durable solutions to optimise hauling operations,” said Josh Swank, Philippi-Hagenbuch vice president of sales and marketing.
“Our Sideboards are a great solution to help producers enable their trucks to haul their full rated capacity. Sideboards offer the simplest, least-expensive way to add volume to a truck body.”
Sideboards are available in 2.54-centimetre increments from 15.24 centimetres to 101.6 centimetres. In some cases, they may be available even larger, depending on the haul truck, the environment, and the material being hauled. The company also considers the operation’s loading equipment to ensure the final height will not exceed the loader’s capabilities.
Philippi-Hagenbuch determines the proper size for sideboards using a calculation based on material density, 2:1 heap capacity, and haul truck body volume. For example, suppose a haul truck’s tonnage capacity is 71 tons, and the volumetric capacity is 52.3 cubic meters at a 2:1 heap. In that case, sideboards add 0.84 cubic meters of volumetric capacity for every centimetre height added to the truck body.
Designed in an upside-down “U” shape, Sideboards fit over the existing body sides and are securely welded to the body. Philippi-Hagenbuch engineers Sideboards to fit the specific make and model of an off-highway haul truck, and the front is “trim to fit” for optimal mating with the front slope of the body. Operations can utilise Sideboards alone or pair them with Philippi-Hagenbuch Autogate Tailgates to further increase capacity and prevent material from spilling from the back of the body.
Philippi-Hagenbuch Sideboards are built of Grade 80 steel for trucks ranging from 20 to 150 tons and 450 Brinell on trucks 150-plus tons for excellent durability. They’re also engineered with internal structural gussets to help provide a long service life. Sideboards can be installed at Philippi-Hagenbuch’s factory in Peoria, Illinois, in the field with Philippi-Hagenbuch supervisory assistance or self-installed by a dealer or customer
